Using BIOS

 CSM parameters

Scroll to this item and press <Enter> to view the following screen.

Main Advanced Chipset M.I.B III Boot Security Exit

+/- : Change Opt.

Enter/Dbl Click : Select

: Select Screen

/Click: Select Item

F1: General Help

F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC/Right Click: Exit

Launch CSM Always

Boot option filter UEFI and Legacy

Launch PXE OpROM policy Do not launch

Launch Storage OpROM policy Legacy only

Launch Video OpROM policy Legacy only

Other PCI device ROM priority Legacy OpROM

Launch CSM

Boot option filter

Launch PXE OpROM policy

This controls the execution of UEFI and Legacy PXE OpROM.

Launch Storage OpROM policy

This controls the execution of UEFI and Legacy Storage OpROM.

Launch Video OpROM policy

This controls the execution of UEFI and Legacy Video OpROM.

Other PCI device ROM priority

For PCI devices other than Network, Mass storage or Video defines which OpROM to

launch.

This option controls if CSM

will be launched

This option controls if CSM will be launched.

Press <Esc> to return to the Boot Menu page.

CSM parameters

OpROM execution, boot options filter,etc.

This option controls what devices system can boot to.

Hard Disk / CD/DVD ROM / USB Floppy / USB CD/DVD ROM / USB HardDisk /

USB Flash / Network Boot Drive Priorities

These items enable you to specify the sequence of loading the operating system.

Press <Enter> to see the submenu.

Questions and Answers:

Need help?

Do you have a question about the ECS A75F-M2 and is the answer not in the manual?

ECS A75F-M2 Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Maximum internal memory	16 GB
Supported memory clock speeds	1333, 1600, 1866 MHz
Processor socket	Socket FM1
Processor manufacturer	AMD
Compatible processor series	AMD Athlon FX, AMD Athlon II X2, AMD Athlon II X3, AMD Athlon II X4, AMD Athlon X2, AMD Athlon X2 Dual-Core
S/PDIF out connector	Yes
Number of SATA III connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
BIOS type	AMI
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A75
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7
On-board graphics card	No
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111E
Networking features	Gigabit Ethernet
