51
Using the Motherboard Software
Chapter 4
Using the Motherboard Software
The auto-install DVD-ROM makes it easy for you to install the drivers and software.
The support software DVD-ROM disc loads automatically under Windows XP/7/8.
When you insert the DVD-ROM disc in the DVD-ROM drive, the auto-run feature
will automatically bring up the installation screen. The screen has four buttons on it:
Setup, Utilities, Browse CD and Exit.
Auto-installing under Windows XP/7/8
Displays the path for all
software and drivers
available on the disk.
Open Windows Explorer
and show the contents
of the support disk.
Click “Exit” button to
close the Auto-Setup
window.
Browse CD:
Click the “Setup
button to select and
run the software
installation program.
Click the Utilities”
button to select and
install ECS Intelligent
Utility.
Information:
Follow these instructions to install device drivers and software for the motherboard:
The following screens are examples only. The screens and driver lists will
be different according to the motherboard you are installing.
1. Click Setup. The installation program begins:
Running Setup
The motherboard identification is located in the upper left-hand corner.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ECS A75F-M2 and is the answer not in the manual?

ECS A75F-M2 Specifications

General IconGeneral
Memory channelsDual-channel
Number of memory slots2
Maximum internal memory16 GB
Supported memory clock speeds1333, 1600, 1866 MHz
Processor socketSocket FM1
Processor manufacturerAMD
Compatible processor seriesAMD Athlon FX, AMD Athlon II X2, AMD Athlon II X3, AMD Athlon II X4, AMD Athlon X2, AMD Athlon X2 Dual-Core
S/PDIF out connectorYes
Number of SATA III connectors6
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports0
BIOS typeAMI
Component forPC
Power source typeATX
Motherboard chipsetAMD A75
Audio output channels6.1 channels
Motherboard form factormicro ATX
Compatible operating systemsWindows 7
On-board graphics cardNo
Parallel processing technology supportNot supported
LAN controllerRealtek RTL8111E
Networking featuresGigabit Ethernet
Weight and Dimensions IconWeight and Dimensions
Depth200 mm
Width240 mm
