ECS A75F-M2 User Manual

56
CrossFire
®
Technology [AMD Dual Graphics] Support
3. Set the CrossFire in Advanced Menu to Enabled. Then press F4 to save the
configuration and exit the BIOS.
4. Click with your right mouse button on My Computer, then click the option
Manage and choose the Device Manager, finally, click the Display Adapters. The
following screen appears. Be sure that the External ATI graphics (ATI Radeon HD
6670) and Onboard graphics (Radeon HD 6530D or HD6550D) are both displaying
in the Display adapters.
Main Advanced Chipset M.I.B III Boot Security Exit
CrossFire: Output is IGD
Video
North Chipset Configuration
IGD Memory Auto
Initate Graphic Adapter IGD
CrossFire Enabled
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
:Select Item

ECS A75F-M2 Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Maximum internal memory	16 GB
Supported memory clock speeds	1333, 1600, 1866 MHz
Processor socket	Socket FM1
Processor manufacturer	AMD
Compatible processor series	AMD Athlon FX, AMD Athlon II X2, AMD Athlon II X3, AMD Athlon II X4, AMD Athlon X2, AMD Athlon X2 Dual-Core
S/PDIF out connector	Yes
Number of SATA III connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
BIOS type	AMI
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A75
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7
On-board graphics card	No
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111E
Networking features	Gigabit Ethernet

Weight and Dimensions

Depth	200 mm
Width	240 mm
