ECS G31T-M9 User Manual

19
Installing the Motherboard
LPT: Onboard parallel port header
This is a header that can be used to connect to the printer, scanner or other devices.
1 STROBE 14 AFD
2 PD0 15 ERROR
3 PD1 16 INIT
4 PD2 17 SLCTIN
5 PD3 18 Ground
6 PD4 19 Ground
7 PD5 20 Ground
Pin Signal Name Pin Signal Name
8 PD6 21 Ground
9 PD7 22 Ground
10 ACK 23 Ground
11 BUSK 24 Ground
12 PE 25 Ground
13 SLCT 26 Key

ECS G31T-M9 Specifications

General

Number of memory slots	2
Maximum internal memory	4 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
CPU fan connector	Yes
USB 2.0 connectors	1
USB 2.0 ports quantity	4
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1708B
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Core2 Duo/ Pentium Dual Core/ Celeron Dual Core/ Celeron 400
Graphics card	GMA 3100
Networking features	Fast Ethernet
ACPI version	1.0
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	170 mm
Width	225 mm
