Introducing the Motherboard

Table of Motherboard Components

LABEL COMPONENTS

LGA775 socket for Intel

Core

™

2 Duo/

Pentium

Dual-Core/Celeron

4xx Series processors

2. CPU_FAN

CPU cooling fan connector

3. DDR2_1~2

240-pin DDR2 SDRAM slots

4. ATX_POWER

Standard 24-pin ATX power connector

5. IDE

Primary IDE channel

6. SPK

Speaker header

7. CLR_CMOS

Clear CMOS

umper

8. F_PANEL

Front Panel switch/LED header

9. F_USB

Front Panel USB header

10. SATA1~2

Serial ATA connectors

11. LPT

Onboard parallel port header

12. F_AUDIO

Front panel audio header

13. PCI1

32-bit add-on card slot

14. CO

Onboard serial port header

15. PCIE

PCI Express x1 slot

16. PCIEX16

PCI Express x16 graphics card slot

Rear Panel USB PS/2 Power Select Jumper (for PS/2

S3 wake-up only)

18. ATX12

4-pin +12V power connector

1. CPU Socket

17. KBMPWR

This concludes Chapter 1. The next chapter explains how to install the motherboard.

Questions and Answers:

Need help?

Do you have a question about the ECS G31T-M9 and is the answer not in the manual?

ECS G31T-M9 Specifications

General

Number of memory slots	2
Maximum internal memory	4 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
CPU fan connector	Yes
USB 2.0 connectors	1
USB 2.0 ports quantity	4
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1708B
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Core2 Duo/ Pentium Dual Core/ Celeron Dual Core/ Celeron 400
Graphics card	GMA 3100
Networking features	Fast Ethernet
ACPI version	1.0
BIOS memory size	32 Mbit
