Page #28 background imageLoading...
Page #28 background image
24
Installing the Motherboard
Users please note that the fan connector supports the CPU cooling fan of
1.1A ~ 2.2A (26.4W max) at +12V.
ATX_POWER: ATX 24-pin Power Connector
CPU_FAN: CPU Cooling FAN Power Connector
1 GND System Ground
3
Sense Sensor
4 PWM PWM
Pin Signal Name Function
2 +12V Power +12V
Pin Signal Name Pin Signal Name
1 +3.3V 13 +3.3V
3 Ground 15 Ground
4 +5V 16 PS_ON
5 Ground 17 Ground
6 +5V 18 Ground
7 Ground 19 Ground
8 PWRGD 20 -5V
9 +5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 Ground
2 +3.3V 14 -12V
ATX12V: ATX 12V Power Connector
Pin Signal Name
4 +12V
3 +12V
2 Ground
1 Ground
SPK: Internal speaker
Pin Signal Name
1 VCC
2 Key
3 NC
4 Signal

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ECS G31T-M9 and is the answer not in the manual?

ECS G31T-M9 Specifications

General IconGeneral
Number of memory slots2
Maximum internal memory4 GB
Processor socketLGA 775 (Socket T)
Processor manufacturerIntel
CPU fan connectorYes
USB 2.0 connectors1
USB 2.0 ports quantity4
Firewire (IEEE 1394) ports0
Audio chipVIA VT1708B
Power source typeATX
Audio output channels5.1 channels
Motherboard form factormicro ATX
Compatible operating systemsCore2 Duo/ Pentium Dual Core/ Celeron Dual Core/ Celeron 400
Graphics cardGMA 3100
Networking featuresFast Ethernet
ACPI version1.0
BIOS memory size32 Mbit
Weight and Dimensions IconWeight and Dimensions
Depth170 mm
Width225 mm
