3
Introducing the Motherboard
This motherboard may support either of the following Audio chipsets:
The motherboard comes with the following expansion options:
• One PCI Express slot for Graphic Interface
• One PCI Express x1 Slot
• One 32-bit PCI v2.3 compliant slot
• One IDE connector that supports two IDE devices
• Two 7-pin SATA connectors
Expansion Options
• 5.1 Channel High Definition Audio Codec
• Exceeds Microsoft Windows Logo Program (WLP) Requirements
• ADCs support 44.1K/48K/96K/192KHz sample rate
• Power Support: Digital: 3.3V; Analog: 5.0V
Audio
Onboard LAN (optional)
The onboard LAN controller provides either of the following features:
• Supports 10/100 Mbps Ethernet Transceiver
• Fully compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab
• Wake-On-LAN (WOL) by Magic Packet/Frame/Link Change
• Integrated PHY for 10/100/1000 Mbps
• IEEE 802.3x compliant flow control support
• Three power supplies: 2.5V, 1.8V and 1.2V
• PCI Express base 1.1 compliant
• Two PS/2 ports for mouse and keyboard
• One VGA port
• Four USB ports
• One LAN port
• Audio jacks for microphone, line-in and line-out
The motherboard has a full set of I/O ports and connectors:
Integrated I/O
1.Some hardware specifications and software items are subject to change
without prior notice.
2.Due to chipset limitation, we recommend that motherboard be oper-
ated in the ambiance between 0 and 50°C.
The firmware can also be used to set parameters for different processor clock
speeds.
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
This motherboard uses AMI BIOS that enables users to configure many system
features including the following:
BIOS Firmware
