Installing the Motherboard
Checking Jumper Settings
The following illustration shows the location of the motherboard jumpers. Pin 1 is
labeled.
Jumper Settings
Jumper
T
y
pe
Description
Setting (default)
CLR_CMOS
3-pin
CLEAR CMOS
1-2: NORMAL
2-3: CLEAR
Before clearing the
CMOS, make sure to
turn the system off.
3-pin
USBPWR_R1
1-2: VCC
2-3: 5VSB
Rear USB/PS2
Power Select
Jumper
3-pin
USBPWR_F1~2
1-2: VCC
2-3: 5VSB
Front Pa
nel
USB Power
Select Jumper
USBPWR_R1
CLR_CMOS
1
USBPWR_F1~2
1
1
USBPWR_R2
Rear USB/PS2
Power Select
Jumper
3-pin
1-2: VCC
2-3: 5VSB
1
USBPWR_R2
12
