ECS G43T-M User Manual

34
Using BIOS
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
Integrated Peripherals
Onboard SATA Mode Enhanced
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Onboard AUDIO Function Enabled
Serial Port1 Address 3F8&IRQ4
Help Item
USB Functions Enabled
Legacy USB Support Enabled
On Chip SATA2 Controller Enabled
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
Onboard SATA Mode (Enhanced)
Use this item to select the mode of the Serial ATA.
Legacy USB Support (Enabled)
Use this item to enable or disable support for legacy USB devices. Setting to Auto
allows the system to detect the presence of USB device at startup. If detected, the
USB controller legacy mode is enabled. If no USB device is detected, the legacy USB
support is disabled.
USB Functions (Enabled)
Use this item to enable or disable the USB function.
OnBoard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
OnBoard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
Serial Port1 Address (3F8/IRQ4)
OnBoard AUDIO Function (Enabled)
Use this item to enable or disable the onboard Audio function.
Use this item to enable or disable the onboard COM1 serial port, and to assign a port
address.
On Chip SATA2 Controller (Enabled)
This item allows you to enable or disable the on chip SATA2 controller.
Press <Esc> to return to the main menu setting page.
Options
Disabled
Compatible
Enhanced
