5
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket
Socket for AMD Phenom™ processor (socket AM2+)/AMD
Athlon™ 64 X2 Dual-Core/Athlon™ 64/Sempron™ processors
2. DIMM1~2 240-pin DDR2 SDRAM slots
3. FDD Floppy disk drive connector
4. PWR1 Standard 24-Pin ATX Power connector
5. IDE1 Primary IDE connector
6. SPK1 Speaker header
7. SATA1~4 Serial ATA connectors
8. CLR_CMOS Clear CMOS jumper
9. PANEL1 Front Panel Switch/LED header
10. USBPWR_F Front Panel USB Power Select jumper
11. F_USB1~4* Front Panel USB headers
12. SYS_FAN System cooling fan connector
13. SPDIFO1 SPDIF out header
14. CD_IN Analog Audio Input header
15. F_AUDIO Front Panel Audio header
16. PCI1~2 32-bit add-on card slots
17. PCIEX1 PCI Express x1 slot
18. PCIEX16 PCI Express x16 graphics card slot
19. USBPWR_R Rear USB/PS2 Power Select jumper
20. PWR2 4-pin +12V power connector
21. CPU_FAN CPU cooling fan connector
“*” stands for optional components.
