Installing the Motherboard

PWR2: ATX 12V Power Connector

Users please note that the fan connector supports the CPU cooling fan of

1.1A ~ 2.2A (26.4W max) at +12V.

PWR1: ATX 24-pin Power Connector

Pin Signal Name Pin Signal Name

1 +3.3V 13 +3.3V

2 +3.3V 14 -12V

3 Ground 15 Ground

4 +5V 16 PS_ON

5 Ground 17 Ground

6 +5V 18 Ground

7 Ground 19 Ground

8 PWRGD 20 -5V

9 +5VSB 21 +5V

10 +12V 22 +5V

11 +12V 23 +5V

12 +3.3V 24 Ground

SYS_FAN: System Cooling FAN Power Connector

Pin Signal Name Function

1 GND System Ground

2 +12V Power +12V

3 Sense Sensor

CPU_FAN: FAN Power Connector

Pin Signal Name

4 +12V

3 +12V

2 Ground

1 Ground

1 GND System Ground

3 Sense Sensor

4 Control CPU FAN control

Pin Signal Name Function

2 +12V Power +12V

Questions and Answers:

Need help?

Do you have a question about the ECS GeForce6100PM-M2 and is the answer not in the manual?

ECS GeForce6100PM-M2 Specifications

General

Number of memory slots	2
Maximum internal memory	16 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	Award
BIOS memory size	64 Mbit
RAID levels	0, 1
