ECS GeForce6100PM-M2 User Manual

35
Using BIOS
Advanced Chipset Setup
This page sets up more advanced information about your system. Handle this page
with caution. Any changes can affect the operation of your computer.
VGA Share Memory (Auto)
This item lets you allocate a portion of the main memory for the onboard VGA
display application.
Press <Esc> to return to the main menu setting page.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Advanced Chipset Setup
Dram Frequency Auto
Dram Timing Auto
DCT Unganged Mode Always
VGA Share Memory Auto
VGA Share Memory Value 32MB
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Dram Frequency (Auto)
This item enables users to adjust the DRAM frequency. The default setting is auto and
we recommend users leave the setting unchanged. Modify it at will may cause the
system to be unstable.
VGA Share Memory Value (32MB)
This item displays the VGA Share Memory Value.
DRAM Timing (Auto)
This item allows you to enable or disable the DRAM timing defined by the Serial
Presence Detect electrical. Users please note that if setting this item to auto, the
following two items are not available.
Options
DCT Unganged Mode (Always)
This item is used to select the DCT mode (DRAM Controller mode).
Auto
Limit
Manual
Options

ECS GeForce6100PM-M2 Specifications

General

Number of memory slots	2
Maximum internal memory	16 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	Award
BIOS memory size	64 Mbit
RAID levels	0, 1
