ECS GeForce6100PM-M2 User Manual

36
Using BIOS
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
Onboard IDE Controller Enabled
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Serial-ATA 0 Enabled
SATA Mode Select SATA Mode
nVidia RAID Setup Press Enter
Onboard AUDIO Function Auto
Onboard LAN Function Auto
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8/IRQ4
Legacy USB Support Enabled
USB Controller Enabled
f
DISABLED: disables the
integrated IDE Control-
ler.
PRIMARY: enables only
the Primary IDE Control-
ler.
SECONDARY: enables
only the Secondary IDE
Controller.
BOTH: enables both IDE
Controllers.
SATA Mode select (SATA Mode)
Use this item to select the mode of the Serial ATA.
OnBoard IDE Controller (Enabled)
Use this item to enable or disable the onboard IDE interface.
Serial-ATA 0 (Enabled)
This item allows you to enable or disable the onboard SATA controller.
nVidia RAID Setup (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
X
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
nVidia RAID Setup
RAID Setup
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk

ECS GeForce6100PM-M2 Specifications

General

Number of memory slots	2
Maximum internal memory	16 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	Award
BIOS memory size	64 Mbit
RAID levels	0, 1
