Introducing the Motherboard

Chapter 1

Introducing the Motherboard

Introduction

Thank you for choosing the GeForce6100PM-M2 motherboard. This motherboard

is a high performance, enhanced function motherboard that supports socket for

AMD Phenom

II/Phenom

processor (socket AM2+)/AMD Athlon

64 X2 Dual-

Core/Athlon

64/Sempron

processors for high-end business or personal desktop

markets.

This motherboard is based on NVIDIA

ΜCP61 Premium media and communications

processor (MCP) for best desktop platform solution. MCP61P is a single-chip,

highly integrated, high performance HyperTransport peripheral controller, unmatched

by any other single chip-device controller. The memory controller supports DDR2

memory

DIMM frequencies of 800/667/533/400. It supports two DDR2 sockets

with maximum memory size of 16 GB. High resolution graphics via one PCI Express

x16 slot, one PCI Express x1 slot, 10 USB 2.0 ports (4 USB ports and 3 USB 2.0

headers support additional 6 USB ports) and SATA support with RAID function.

There is an advanced full set of I/O ports in the rear panel, including PS/2 mouse and

keyboard connectors, COM1, LPT (optional), VGA1, four USB ports, one LAN port

and audio jacks for microphone, line-in and 6/8-channel (optional) line-out. This

motherboard is designed in a Micro ATX form factor using a four-layer printed circuit

board and measures 244 mm x 214 mm.

Due to the DRAM maximum size is 4 GB at present, the memory maximum

size we have tested is 8 GB.

Questions and Answers:

Need help?

Do you have a question about the ECS GeForce6100PM-M2 and is the answer not in the manual?

ECS GeForce6100PM-M2 Specifications

General

Number of memory slots	2
Maximum internal memory	16 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	Award
BIOS memory size	64 Mbit
RAID levels	0, 1
