ECS GeForce6100PM-M2 User Manual

40
Using BIOS
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
Smart Fan Function
f
Scroll to this item and press <Enter> to view the following screen:
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Disabled
Enabled
Options
SMART Fan Control Enabled
SMART Fan Start PWM value 40
SMART Fan start TEMP. (
°C) 50
DeltaT +3
SMART Fan Slope PWM value 4 PWM value/
°C
SMART Fan Control (Enabled)
This item allows you to enable or disable the control of the CPU fan speed by
changing the fan voltage.
SMART Fan start PWM value (40)
This item is used to set the start PWM value of the smart fan.
SMART Fan start TEMP. (50)
This item is used to set the start temperature of the smart fan.
Smart FAN Slope PWM value (4 PWM value)
This item is used to set the Slope Select PWM of the smart fan.
This item specifies the range that controls CPU temperature and keeps it
from going so high or so low when smart fan works.
DeltaT (+3)
Press <Esc> to return to the PC Health Status page.
Shutdown Temperature (Disabled)
This item nables you to set the maximum temperature the system can reach before
powering down.

ECS GeForce6100PM-M2 Specifications

General

Number of memory slots	2
Maximum internal memory	16 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	Award
BIOS memory size	64 Mbit
RAID levels	0, 1
