Introducing the Motherboard

Table of Motherboard Components

This concludes Chapter 1. The next chapter explains how to install the motherboard.

* stands for optional components

LABEL COMPONENTS

Socket for AMD Phenom

II/Phenom

processor (socket AM2+)/

AMD Athlon

64 X2 Dual-Core/Athlon

64/Sempron

processors

2. DIMM1~2 240-pin DDR2 SDRAM slots

3. FDD Floppy disk drive connector

4. PWR1 Standard 24-Pin ATX Power connector

5. IDE1 Primary IDE connector

6. SPK1 Speaker header

7. SATA1~4 Serial ATA connectors

8. IR1* Infrared header

9. CLR_CMOS Clear CMOS jumper

10. PANEL1 Front Panel Switch/LED header

11. USBPWR_F Front Panel USB Power Select jumper

12. F_USB1~3 Front Panel USB headers

13. SYS_FAN System cooling fan connector

14. SPDIFO1 SPDIF out header

15. CD_IN Analog Audio Input header

16. F_AUDIO Front Panel Audio header

17. PCI1~2 32-bit add-on card slots

18. PCIEX1 PCI Express x1 slot

19. PCIEX16 PCI Express x16 graphics card slot

20. USBPWR_R Rear USB/PS2 Power Select jumper

21. PWR2 4-pin +12V power connector

22. CPU_FAN CPU cooling fan connector

1. CPU Socket

Questions and Answers:

Need help?

Do you have a question about the ECS GeForce6100PM-M2 and is the answer not in the manual?

ECS GeForce6100PM-M2 Specifications

General

Number of memory slots	2
Maximum internal memory	16 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	Award
BIOS memory size	64 Mbit
RAID levels	0, 1
