5
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket LGA775 socket for Intel
®
Core
™
2 Duo CPUs
2. CPU_FAN CPU cooling fan connector
3. DDR2_1~2 240-pin DDR2 SDRAM slots
4. ATX_POWER Standard 24-Pin ATX Power connector
5. FDD Floppy disk drive connector
6. IDE Primary IDE connector
7. SATA1~4 Serial ATA connectors
8. SYS_FAN System cooling fan connector
9. CLR_CMOS Clear CMOS jumper
10. SPK Speaker header
11. F_PANEL Front panel Switch/LED header
12. LPT* Onboard parallel port header
13. USBPWR_F Front panel USB Power Select jumper
14. F_USB1~3 Front panel USB headers
15. SPDIFO SPDIF out header
16. CD_IN Analog Audio Input header
17. F_AUDIO Front panel Audio header
18. PCI1~2 32-bit add-on card slots
19. PCIEX16 PCI Express x16 graphics card slot
20. PCIE1 PCI Express x1 slot
21. USBPWR_R Rear panel USB/PS2 Power Select jumper
22. ATX12V 4-pin +12V power connector
* Stands for optional components
