Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
Integrated Peripherals
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
SATA Mode
RAID Mode
AHCI Mode
Options
SATA Mode select (SATA Mode)
Use this item to select the mode of the Serial ATA.
OnBoard IDE Controller (Enabled)
Use this item to enable or disable the onboard IDE interface.
OnChip S-ATA Controller (Enabled)
This item allows you to enable or disable the onboard SATA controller.
Onboard AUDIO Function (Enabled)
Use this item to enable or disable the onboard audio device.
OnBoard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
OnBoard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
Serial Port1 Address (3F8/IRQ4)
Use this item to enable or disable the onboard COM1/2 serial port, and to assign a
port address.
Parallel Port Address (378)
Use this item to enable or disable the onboard Parallel port, and to assign a port
address.
Onboard IDE Controller Enabled
OnChip S-ATA Controller Enabled
SATA Mode Select SATA Mode
Onboard Audio Function Enabled
HDMI Audio Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8/IRQ4
Parallel Port Address 378
Parallel Port Mode Normal
Parallel Port IRQ IRQ7
USB Controller Enabled
Legacy USB Support Enabled
HDMI Audio Function (Enabled)
Use this item to enable or disable the chipset HDMI (High Definition
MultimediaInterface) Audio function.
