Frequency/Voltage Control
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have in-
stalled in your system.
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
Frequency/Voltage Control
Help Item
Options
Disabled
Enabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Manufacturer: Intel
Ratio Status: Unlocked (Min: 06, Max: 07)
Ratio Actual Value: 7
Auto Detect DIMM/PCI CIK Enabled
CPU BSEL Select Auto
PCIE Spread Spectrum Disabled
DIMM Voltage Control 1.90V
NB Voltage Control 1.375V
Manufacturer (Intel)
This item shows the brand of the CPU installed in your system.
Ratio Status/Ratio Actual Value (Unlocked/7)
These items show the locked/unlocked ratio status and the actual ratio of the CPU
installed in your system.
Shutdown Temperature (Disabled)
This item enables you to set the maximum temperature the system can reach before
powering down.
Press <Esc> to return to the main menu setting page.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan
speed,...etc.
• VDIMM
• System Temperature
• CPU Temperature
• CPU Fan Speed
• CPU Vcore
Auto Detect DIMM/PCI Clk (Enabled)
When this item is enabled, BIOS will disable the clock signal of free DIMM/PCI slots.
CPU BSEL Select (Auto)
This item is used to select the CPU BSEL.
