ECS H57H-M User Manual

20
Installing the Motherboard
GPS/DPS: Graphics processor sensor/Discrete processor sensor
The GPS indicator LED shows if the installed CPU contains embedded graphics
engine. When GPS LED is turned on, you may connect the display monitor directly
to the mainboard’s graphics port. (You may also choose to use a VGA adaptor card.)
In contrary, the DPS LED turns on if the CPU does not contain embedded graphics
and thus require a VGA adaptor card to connect the display monitor.
IPS_LED: Intelligent Power Saving
IPS is an advanced power system that provides better energy efficiency for the
processors. The energy canbe greatly saved during idle operation or other low load
conditions which can be confirmed through IPS indicator LEDs.
Green: LIGHT LOAD 1
Green: LIGHT LOAD 2
Yellow: NORMAL LOAD 1
Yellow: NORMAL LOAD 2
Red: FULL LOAD 2
Red: FULL LOAD 1

ECS H57H-M Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
System bus rate	2.5 GT/s
Processor socket	LGA 1156 (Socket H)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA II connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
BIOS type	AMI
BIOS memory size	64 Mbit
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H57
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7
Parallel processing technology support	Not supported
PCI Express slots version	2.0
RAID levels	0, 1, 5, 10
LAN controller	Realtek RTL8111D(L)
Ethernet interface type	Gigabit Ethernet

Weight and Dimensions

Width	244 mm
