ECS H57H-M

38
Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Help Item
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
PC Health Status
: Move F10: Save ESC: Exit
+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help

-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
CPU Temperature 43°C/109°F
Syste
m Temperature 31°C/87°F
CPU Fan Speed: 2096 RPM
System Fan Speed: N/A
CPU Vcore: 1.128V
VDIMM: 1.512V
Case Open Warning Disabled
Chassis Opened No

Smart Fan Function (Press Enter)

Scroll to this item and press <Enter> to view the following screen:
SMART Fan Control (Enabled)
This item allows you to enable/disable the control of the CPU fan speed by changing
the fan voltage.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
Options

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
CPU Smart Fan Control Enabled
SMART Fan Mode Normal
CPU Fan start PWM 56
CPU SAMRT Fan start TEMP(°F)32
DeltaT +3
SMART Fan Slope PWM value 4 PWM value/°F
CPU FAN Full Limit Temp 81°F
Disabled
Enabled
