ECS H57H-M User Manual

39
Using BIOS
SMART Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be auto
adjusted depending on the CPU temperature. If you choose Quite mode, the fan speed
will be auto minimized for quiet environment. If you choose Silent mode, the fan
speed will be auto restricted to make system more quietly. If you choose Manual
mode, the fan speed will be adjust depending on users’ parameters.
Press <Esc> to return to the Smart Fan Function page.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
Options

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
CPU Smart Fan Control Enabled
SMART Fan Mode
Normal
CPU Fan start PWM 56
CPU SAMRT Fan start TEMP(°F)32
DeltaT +3
SMART Fan Slope PWM value 4 PWM value/°F
CPU FAN Full Limit Temp 81°F
Disabled
Enabled
Press <Esc> to return to the Smart Fan Function page.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
Options

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
CPU Smart Fan Control Enabled
SMART Fan Mode Quiet
CPU Fan start PWM 30
CPU SAMRT Fan start TEMP(°F)29
DeltaT +3
SMART Fan Slope PWM value 5 PWM value/°F
CPU FAN Full Limit Temp 74°F
Normal: auto adjusts de-
pending on the CPU tem-
perature.
Quiet: auto minimizes fan
speed for quiet environ-
ment operation.
Silent: auto restricts fan
speed to make system
more quietly.
Manual: the fan adjust de-
pending on user’s param-
eter.

ECS H57H-M Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
System bus rate	2.5 GT/s
Processor socket	LGA 1156 (Socket H)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA II connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
BIOS type	AMI
BIOS memory size	64 Mbit
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H57
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7
Parallel processing technology support	Not supported
PCI Express slots version	2.0
RAID levels	0, 1, 5, 10
LAN controller	Realtek RTL8111D(L)
Ethernet interface type	Gigabit Ethernet

Weight and Dimensions

Width	244 mm
