32
Using BIOS
Advanced Setup
This page sets up more advanced information about your system. Handle this page
with caution. Any changes can affect the operation of your computer.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Advanced Setup
Thermal Management Enabled
TM Status TM1/TM2
Limit CPUID MaxVal Disabled
Enhanced Halt (C1E) Enabled
Intel XD Bit Disabled
Intel VT Enabled
Intel EIST Enabled
Intel (R) HT Technology Enabled
Intel (R) TurboMode tech Enabled
Quick Power on Self Test Enabled
Boot Up Numlock Status On
APIC Mode Enabled
1st Boot Device Hard Drive
2nd Boot Device CD/DVD
3rd Boot Device Removable Dev.
Boot Other Device Yes
ECS eJIFFY Function Disabled
CPU Thermal monitor.
Help Item
Enhanced Halt (C1E) (Disabed)
This item enables or disables enhanced halt.
: Move F10: Save ESC: Exit
+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help

Thermal Management (Enabled)
This item displays CPU’s temperature and enables you to set a safe temperature to
Prescott CPU.
TM Status (TM1/TM2)
This item displays CPU Monitor status.
Limit CPUID MaxVal (Disabled)
Use this item to enable or disable the Max CPU ID value limit. When suppports
Prescott a
nd LGA775 CPUs, enable this to prevent the system from “rebooting”
when trying to install Windows NT 4.0.
Enhanced Halt (C1E) (Enabled)
This item enables or disables enhanced halt (C1E).
Intel XD Bit (Disabled)
This item allows users to enable or disable the Intel XD bit.
Intel VT (Enabled)
When enabled, a VMM can utilize the additional hardware capabilities provided by
Vandor Pool Technology.
Intel EIST (Enabled)
This item allows users to enable or disable the EIST (
Enhanced Intel SpeedStep
technology).
