43
Using BIOS
PCIE Over-clocking Func (Disabled)
This item enables or disables the PCIE over-clocking function.
Spread Spectrum (Enabled)
If you ena
ble spread spectrum, it can significantly reduce the EMI (Electro-Magnetic
Interference) generated by the system.
Voltage Function (Disabled)
Use this ite
m to enable or disable the Voltage Function. If enable, users can increase
the hardware voltage through BIOS settings.
Auto Detect DIMM/PCI Clk (Enabled)
When this item is enabled, BIOS will disable the clock signal of free DIMM/PCI slots.
Warning: Please pay attention that doing overvoltage may result in damage to
hardware.
PCH Voltage (1.152V)
This item allows users to adjust the PCH voltage.
Intel (R) Core (TM) 15 CPU 650 @ 3.20 GHz
This is display-only field and displays the information of the CPU installed in your
computer.
Press <Esc> to return to the main menu setting page.
Ratio Status: Unlocked (Min: 09, Max: 24)
These items show the locked/unlocked ratio status and the actual ratio of the CPU
installed in your system.
Current Memory Frequency (1333MHz)
This item displays the current memory frequency.
CPU Vcore (1.128 V)
This item displays the current CPU voltage.
VDIMM (1.512 V)
This item displays the current DIMM voltage.
Meomory Current Type (9-24-9-9-10-100-5-4-5-20)
These items show the information of the memory current type.
To Next Page
