Introducing the Motherboard

Table of Motherboard Components

This concludes Chapter 1. The next chapter explains how to install the motherboard.

LABEL COMPONENTS

LGA1155 socket for for latest new Sandy Bridge high-end

desktop processors

2. CPU_FAN CPU cooling fan connector

3. DDR3_1~2 240-pin DDR3 SDRAM slots

4. ATX_POWER Standard 24-pin ATX power connector

5. SYS_FAN System cooling fan connector

6. SATA1~4 SATA 3Gb/s connectors

7. PWR_FAN Power cooling fan connector

8. F_PANEL Front panel switch/LED header

9. SPI_DEBUG SPI debug header-for factory use only

10. F_USB2 Front panel USB 2.0 header (F_USB2 supports EZ Charger)

11. F_USB1 Front panel USB 2.0 header

12. CLR_CMOS Clear CMOS jumper

13. SPK Internal speaker header

14. COM Onboard serial port header

15. CASE CASE open header

16. ME_UNLOCK ME unlock header-for factory use only

17. LPT Parallel port header

18. F_AUDIO Front panel audio header

19. SPDIFO SPDIF out header

20. PCI1~2 32-bit add-on card slots

21. PCIE1~3 PCI Express x1 slots

22. PCIEX16 PCI Express x16 slot for graphics interface

23. ATX12V 4-pin +12V power connector

1. CPU Socket

Other manuals for ECS H61H2-A

Questions and Answers:

Need help?

Do you have a question about the ECS H61H2-A and is the answer not in the manual?

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Power fan connector	Yes
Number of SATA II connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Component for	PC
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	ATX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express x1 slots	3
LAN controller	Realtek RTL8111E
Networking features	Gigabti Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	AMI
ACPI version	3.0
BIOS memory size	32 Mbit
