Introducing the Motherboard

Chapter 1

Introducing the Motherboard

Introduction

Thank you for choosing H61H2-A motherboard. This motherboard is a high

performance, enhanced-function motherboard designed to support the LGA1155

socket for latest new Sandy Bridge high-end processors to reach the optimum

system performance for high-end business or personal desktop market.

This motherboard is based on Intel

H61 Chipset for best desktop platform solution.

H61 is a single-chip, highly integrated, high performance Hyper-Threading periph-

eral controller, unmatched by any other single chip-device controller. This

motherboard supports up to 16 GB of system memory with dual channel DDR3

1333/1066 SDRAM. It supports one PCIe x16 Gen 2.0 graphic interface, that

allows you install up to one graphic card with multiple GPU running at PCIe Gen

2.0 speed. It provides two PCI rev 2.2 slots and three PCI Express x1 rev 2.0 slots

for extending usage. It implements an EHCI compliant interface that provides

standard eight USB 2.0 ports (four rear I/O ports and two headers support additional

four USB 2.0 ports and one of Front USB 2.0 headers provide EZ charger technology,

please refer to chapter 2 parts of Front Panel USB headers for more details).

The motherboard is equipped with advanced full set of I/O ports in the rear panel,

including one PS/2 mouse and PS/2 keyboard connectors, one LAN port, four USB

2.0 ports, one VGA port, and audio jacks for microphone, line-in and 6-ch line-out.
