Installing the Motherboard

F_USB1~2(USB 2.0): Front Panel USB 2.0 headers

The motherboard has two USB 2.0 headers supporting four USB 2.0 ports. Addition-

ally, some computer cases have USB 2.0 ports at the front of the case. If you have

this kind of case, use auxiliary USB 2.0 connector to connect the front-mounted

ports to the motherboard.

1 USBPWR Front Panel USB Power

2 USBPWR Front Panel USB Power

3 USB_FP_P0- USB Port 0 Negative Signal

4 USB_FP_P1- USB Port 1 Negative Signal

5 USB_FP_P0+ USB Port 0 Positive Signal

6 USB_FP_P1+ USB Port 1 Positive Signal

7 GND Ground

8 GND Ground

9 Key No pin

10 USB_FP_OC0 N/A

Pin Signal Name Function

Unlike F_USB1 in this mainboard, F_USB2 supports EZ Charger technology, pro-

vides about 1A current than general USB port in off mode for USB devices. It is useful

and excellent, especially for the iPhone, iPad and iPod touch devices that need a

large amount of current for faster recharging within less time.

Please make sure that the USB cable has the same pin assignment as

indicated above. A different pin assignment may cause damage or system

hang-up.

CASE: Chassis Intrusion Detect Header

Short Chassis cover is removed

Open Chassis cover is closed

This detects if the chassis cover has been removed. This function needs a chassis

equipped with instrusion detection switch and needs to be enabled in BIOS.

Pin 1-2 Function

ME_UNLOCK: ME Unlock Header

Short Unlock

Open Lock

Pin 1-2 Function
