Using BIOS
-=- PECI Mode -=-
Offset to TCC Activation Temp : -27
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(-) 30
Delta T +3
Smart Fan Slope PWM value 10 PWM value/unite
CPU Fan Full Speed Offset (-) 23
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset M.I.B III Boot Security Save & Exit
Version 2.11.1210. Copyright (C) 2011, American Megatrends, Inc.
+/- :Change Opt.
Enter : Select
F1:General Help
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
CPU Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
Scroll to this item and press <Enter> to view the following screen:
Smart Fan Function
CPU Smart FAN Control (Enabled)
This item allows you to enable/disable the control of the CPU fan speed by changing
the fan voltage.
SMART Fan start PWM value (180)
SMART Fan start TEMP(-) (30)
This item is used to set the start PWM value of the smart fan.
This item is used to set the start temperature of the smart fan.
DeltaT (+3)
This item specifies the range that controls CPU temperature and keeps it from going
so high or so low when smart fan works.
SMART Fan Slope PWM value (10 PWM value/unite)
This item is used to set the Slope Select PWM of the smart fan.
This item is used to set the CPU fan full speed offset value.
CPU Fan Full Speed Offset(-) (23)
Smart Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be
auto adjusted depending on the CPU temperature. If you choose Quite mode, the fan
speed will be auto minimized for quiet environment. If you choose Silent mode, the
fan speed will be auto restricted to make system more quietly. If you choose Manual
mode, the fan speed will be adjust depending on users’ parameters.
Press <Esc> to return to the PC Health Status page.
