ECS H61H2-M17 User Manual

Chapter 3
H61H2-M17 USER MANUAL
54
CD/DVD ROM Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing CD/DVD ROM drive.
USB/Floppy Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB/IDE Floppy drive.
This page enables you to set the keyboard NumLock state.
Boot Menu
Main Advanced Chipset M.I.B III Boot Security Exit
Select the keyboard
NumLock state
Boot Configuration
Bootup NumLock State On
Set Boot Priority
1st Boot Hard Disk: HDS72808...
2nd Boot CD/DVD: SONY DVD...
3rd Boot USB/Floppy
4th Boot USB CD/DVD
5thBoot USB Hard Disk
6thBoot USB Flash
7th Boot Network
8th Boot UEFI
Hard Disk Drive Priorities [Press Enter]
CD/DVD ROM Drive Priorities [Press Enter]
USB/ Floppy Drive Priorities [Press Enter]
USB CD/DVD ROM Drive Priorities [Press Enter]
USB HardDisk Drive Priorities [Press Enter]
USB Flash Drive Priorities [Press Enter]
Network Device Priorities [Press Enter]
UEFI Boot Drive Priorities [Press Enter]
Bootup NumLock State (On)
This item enables you to select NumLock state.
1st/2nd/3rd/4th/5th/6th/7th/8th Boot
These items show the boot priorities.
+/- : Change Opt.
Enter/Dbl Click : Select
“¤
«‹
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Hard Disk Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing hard disk drive.
USB CD/DVD ROM Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB CD/DVD ROM drive.
USB HardDisk Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB HardDisk drive.
