ECS H61H2-TI User Manual

Chapter 3
H61H2-TI USER MANUAL
50
This page enables you to set the keyboard NumLock state.
Boot Menu
Main Advanced Chipset Frequency/Voltag Boot Security Exit
Windows 7 or other OS:
Boot policy for Legacy OS
Windows 8: Boot policy for
UEFI OS without
Compatibility Support
Module(CSM)
Manual: User customized
CSM parameters & boot
policy
Boot Configuration
Operation System Select Windows 7 or other OS
Launch PXE OpROM Disabled
Launch Strorage OpROM Enabled
Bootup NumLock State On
Boot mode select LEGACY
Set Boot Priority
Boot Option #1 Hard Disk
Boot
Option #2 CD/DVD
Boot Option #3 USB/Floppy
Boot Option #4 USB CD/DVD
Boot Option #5 USB Hard Disk
Boot Option #6 USB Flash
Boot Option #7 Network
Boot Configuration
This item shows the information of the Boot Configuration.
Operation System Select (Windows 7 or other OS)
This item is used to select the operation system.
Launch PXE OpROM (Disabled)
The item enables or disables launch PXE Option ROM.
Launch Storage OpROM (Enabled)
Use this item to enable or disable the Storage OpROM.
Bootup NumLock State (On)
This item enables you to select NumLock state.
Boot mode select (LEGACY)
Use this item to select boot mode.
Set Boot Priority
This item enables you to set boot priority for all boot devices.
Boot Op
tion #1/2/3/4/5/6/7
These items show the boot priorities.
+/- : Change Opt.
Enter : Select


: Select Screen
: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC : Exit
