H61H2-TI USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
LGA1155 socket for latest Intel® Core
TM
Family/
Pentium®/Celeron® Processors
2. DMIC Digital microphone header (optional)
3. SPEAKER 2 Channels audio speaker header (optional)
4. F_AUDIO Front panel audio header
5. PCIE2
Mini PCI Express x 1 slot (supports full-card and
you can install a Mini SATA (mSATA) card into it)
6. CASE Case open header
7. CLR_CMOS Clear CMOS jumper
8. PCIE1 Mini PCI Express x 1 slot (supports half-card)
9. SATA1~2 Serial ATA 3Gb/s connectors
10. SPK Buzzer header
11. LPC Low pin count header
12. ME_DIS ME enable/disable jumper
13. SATA_PWR SATA power connector
14. F_USB Front panel USB 2.0 headers
15. TOUCH Touch board header
16. CAMERA CCD header
17. F_PANEL Front panel switch/LED header
18. SYS_FAN 4-pin system cooling fan connector
19. CPU_FAN 4-pin CPU cooling fan connector
20. MCR Memory card reader header
21. CIR Consumer infrared
22. LVDS LVDS connector (optional)
23. LCD_MODE LCD mode select header (optional)
24. BKLT_CTRL LCD panel backlight control (optional)
25. DIMM1~2 204-pin DDR3 SDRAM SO-DIMMs
1. CPU Socket
