ECS Mainboard User Manual

25
Features Setup Page
This page sets up some parameters for peripheral devices
connected to the system.
CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc.
Features Setup
OnBoard Floppy Controller Enabled
Serial Port Address 3F8/IRQ4
OnBoard IR Port Disabled
Parallel Port Address 378
Parallel Port Mode ECP
ECP Mode DMA Channel DMA3
Parallel Port IRQ IRQ7
OnBoard PCI IDE Controller Both
Audio Device Enabled
Modem Device Auto
Ethernet Device Enabled
OnBoard USB Function Enabled
USB Function for DOS Disabled
OnBoard
Floppy
Controller
Use this item to enable or disable the
onboard floppy disk drive interface.
Serial Port
Address
Use this item to enable or disable the
onboard COM1/2 serial port, and to assign
a port address.
OnBoard IR
Port
Use this item to enable or disable the
onboard infrared port, and to assign a port
address.
Parallel Port
Address
Use this item to enable or disable the
onboard Parallel port, and to assign a port
address.
Parallel Port
Mode
Use this item to set the parallel port mode.
You can select SPP (Standard Parallel Port),
ECP (Extended Capabilities Port), EPP
(Enhanced Parallel Port), or ECP + EPP.
ECP Mode
DMA Channel
Use this item to assign a DMA channel to
the parallel port.
Parallel Port
IRQ
Use this item to assign IRQ to the parallel
port.
Allows BIOS to
Enable or Disable
Floppy Controller.
Hel
p
Item
