ECS NM70-M User Manual

7
NM70-M USER MANUAL
Chapter 1
6. Line-in (blue)
It can be connected to an external CD/DVD player, Tape player or other audio
devices for audio input.
7. Line-out (lime)
It is used to connect to speakers or headphones.
8. Microphone (pink)
It is used to connect to a microphone.
9. HDMI Port (DVI port optional)
You can connect the display device to the HDMI/DVI port.
10. PS/2 Keyboard (purple)
Use the lower PS/2 port to connect a PS/2 keyboard.

ECS NM70-M Specifications

General

Brand	ECS
Model	NM70-M
Category	Motherboard
Language	English
