Chapter 3
NM70-M USER MANUAL
39
Super IO Chip (F71869)
This item shows the information of the super IO chip.
Super IO Configuration
Use this item to show the information of Super IO configuration.
Super IO Configuration
Super IO Chip F71869
Serial Port 0 Configutation
Serial Port 1 Configuration
Parallel Port Configuration
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Main
Advanced Chipset Tweak Boot Security Exit
Version 2.15.1229. Copyright (C) 2012 American Megatrends, Inc.
Set Parameters of Serial Port
0 (COMA)
F1:General Help
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Serial Port 0 Configuration
Scroll to this item and press <Enter> to view the following screen:
Serial Port (Enabled)
This item allows you to enable or disable serial port.
Device Settings (IO=3F8h; IRQ=4)
This item shows the information of the device settings.
Change Settings (Auto)
Use this item to change device settings.
Serial Port 0 Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4;
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012 American Megatrends, Inc.
Enabled or Disabled Serial Port
(COM)
Change Settings [Auto]
Main Advanced Chipset Tweak Boot Security Exit
F1:General Help
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Press <Esc> to return to the Super IO Configuration page.
