PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Main Advanced Chipset Tweak Boot Security Exit
CPU Fan Speed : 1206 RPM
System Fan Speed : 0 RPM
CPU Voltage : 0.984 V
DIMM Voltage : 1.520 V
Version 2.15.1229. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -40
F1:General Help
+/- : Change Opt.
Enter : Select


:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Smart Fan Function

PC Health Status
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012 American Megatrends, Inc.
CPU Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
High Limit Offset (-) : 30
Low Limit Offset (-) : 40
High Limit PWM : 200
Low Limit PWM : 58
System Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
High Limit Offset (-) : 30
Low Limit Offset (-) : 40
High Limit PWM : 200
Low Limit PWM : 58
Main Advanced Chipset Tweak Boot Security Exit
Scroll to this item and press <Enter> to view the following screen:
Smart Fan Function

F1:General Help
+/- : Change Opt.
Enter : Select

:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
CPU/System Smart Fan Control (Enabled)
This item allows you to enable/disable the control of the CPU/System fan speed by
changing the fan voltage.
Smart Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be
auto adjusted depending on the CPU temperature. If you choose Quiet mode, the
fan speed will be auto minimized for quiet environment. If you choose Silent mode,
the fan speed will be auto restricted to make system more quietly. If you choose
Manual mode, the fan speed will be adjust depending on users’ parameters.
Press <Esc> to return to the PC Health Status page.

