Chapter 3
NM70-M USER MANUAL
32
•
CPU Fan Speed
•
System Fan Speed
•
CPU Voltage
•
DIMM Voltage
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System temperature, CPU & DIMM voltage, CPU & System fan speed... etc.
Press <Esc> to return to the Advanced Menu page.
