NM70-M USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Onboard Intel® Celeron ICP1037U/847/807 or other Processors
2. SYS_FAN 3-pin system cooling fan connector
3. CPU_FAN 3-pin CPU cooling fan connector
4. DDR3_1~2 240-pin DDR3 SDRAM slots
5. ATX_POWER Standard 24-pin ATX power connector
6. SATA1 Serial ATA 6Gb/s connector
7. SATA2~4 Serial ATA 3Gb/s connectors
8. BZ Buzzer (optional)
9. ME_UNLOCK ME unlock header-for factory use only
10. SPDIFO SPDIF out header
11. CLR_CMOS Clear CMOS jumper
12. F_PANEL Front panel switch/LED header
13. CASE Case open header
14. F_USB1~2 Front panel USB 2.0 headers
15. PCIEX16 PCI Express slot for Graphics Interface
16. PCIE1~2 PCI Express X1 slots
17. F_AUDIO Front panel audio header
18. LDC Debug card header
19. COM2 Onboard serial port header
20. LPT Onboard parallel port header
