ECS P4VXASD2 User Manual

Load Optimal Settings
If you select this item and press Enter a dialog box appears. If you press Y,
and then Enter, the Setup Utility loads a set of fail-safe default values. These
default values are not very demanding and they should allow your system to
function with most kinds of hardware and memory chips.
Load Best Performance Settings
If you select this item and press Enter a dialog box appears. If you press Y,
and then Enter, the Setup Utility loads a set of best-performance default val-
ues. These default values are quite demanding and your system might not
function properly if you are using slower memory chips or other low-
performance components.
Features Setup Page
This page sets some of the parameters for peripheral devices connected to
the system.
AMIBIOS SETUP – FEATURES SETUP
(C) 2000 American Megatrends, Inc. All Rights Reserved
OnBoard FDC Enabled
OnBoard Serial PortA 3F8h/COM1
OnBoard Serial PortB 2F8h/COM2
Serial Port2 Mode Normal
OnBoard Parallel Port 378h
Parallel Port Mode SPP
Parallel Port IRQ 7
Parallel Port DMA N/A
OnBoard Game Port 201h
OnBoard MIDI Port 300
MIDI Port IRQ 10
OnBoard IDE Both
OnBoard LAN Enabled
OnBoard AC’97 Audio Enabled
OnBoard MC’97 Modem Auto
USB Controller All USB Port
USB Device Legacy Support Disabled
ESC : Quit ↑↓←→ : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
OnBoard FDC
Use this item to enable or disable the onboard floppy disk drive interface.
OnBoard Serial Port A/B
Use these items to enable or disable the onboard COM1/2 serial port, and to
assign a port address.
OnBoard Parallel Port
Use this item to enable or disable the onboard LPT1 parallel port, and
to assign a port address. The Auto setting will detect and available
address.
