ECS P4VXASD2 User Manual

CPU PnP Setup Page
This page helps you manually configure the mainboard for the CPU. The sys-
tem will automatically detect the type of installed CPU and make the
appropriate adjustments to the items on this page.
AMIBIOS SETUP – CPU PnP SETUP
(C) 2000 American Megatrends, Inc. All Rights Reserved
CPU BRAND INTEL
CPU Type Pentium 4
CPU Speed 800 MHz
CPU Ratio Selection 8.0x
CPU Frequency 100 MHz
ESC : Quit ↑↓←→ : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load Optimal values
F7 : Load Best performance values
CPU BRAND/Type/Core Voltage/Ratio/Frequency
These items show the type, core voltage, ratio and frequency of CPU installed
in your system.
CPU Speed
This item decides CPU speed installed in your system.
Hardware Monitor Page
This page helps you manually configure the mainboard for the CPU. The sys-
tem will automatically detect the type of installed CPU and make the
appropriate adjustments to the items on this page.
AMIBIOS SETUP – HARDWARE MONITOR
(C) 2000 American Megatrends, Inc. All Rights Reserved
*** System Hardware ***
Vocore 1.632V
Vcc 2.5V 2.496V
Vcc 3.3V 3.392V
Vcc 5V 4.972V
+12V 11.968V
-12V -0.907V
SB5V 5.053V
VBAT 3.488V
SYSTEM Fan Speed 0 RPM
CPU Fan Speed 1350 RPM
Power Temperature 32°C/89°F
SYSTEM Temperature 39°C/102°F
CPU Temperature 55°C/131°F
ESC : Quit ↑↓←→ : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
