Acclarix AX3 Series Diagnostic Ultrasound System User Manual Getting Started
- 13 -
No.
Name
Description
1
Monitor
Display the images and parameters during
scanning.
2
Power Switch
Power on/off the system.
3
Touch Screen
Use to control operation and activate
functions.
4
Control Panel
Use to control the operation .
5
AC Power Indicator
It illuminates when the system is connected to
AC power.
It is off when the system is no connected to
AC power
System Working Indicator
It illuminates when system is running, and it is
off when the system is shutdown.
Battery Indicator
It is off when no battery is connected or
battery is fully charged.
It illuminates in orange when battery is low.
It illuminates in green when the system
operates on battery power or the battery is
charging.
6
Transducer Locking Lever
Use to lock or unlock the transducer.
7
Transducer Port
Used for connecting a transducer to the
system.
8
Handle
Used for carrying the system.
9
Safety Lock Connector
Used for connecting a safety lock to the
system.
10
Vents
Used for heat dissipation and ventilation.
11
I/O Ports
Use to connect the I/O extend modules.
Table 3-3 Main Unit Description
CAUTION
1. Ensure system vents are clear and unobstructed. Bad ventilation will result in high
system temperature. When the high temperature warning "System Temperature is
High. Please check the system for good ventilation" displays, refer to section 13.2
Troubleshooting for the specific troubleshooting steps.
2. Excessive dust and dirt could clog internal airflow and cause overheating. Do not use
in a dusty environment.
