Acclarix AX3 Series Diagnostic Ultrasound System User Manual Getting Started
- 14 -
I/O Ports on the left panel:
Figure 3-2 I/O ports
1.
Power supply
2.
Network port
3.
S-Video output port
4
HDMI port
5
USB 3.0 port
6
USB 2.0 port
7.
USB 2.0 port
Table 3-4 I/O Ports
Caution
1. The HDMI port does not support "hot plug" feature. Please connect the external
display to the HDMI port before starting the ultrasound system. Otherwise the
external display may be unrecognized or display abnormally.
1
2
3
4
5
6
7
