CADENCE II Fetal Monitor User Manual
- 41 -
Figure 7-3 Separate the introducer
9) Anchoring the catheter in place with one hand, pull the introducer straight back off the
catheter. (See figure 7-4)
Figure 7-4 Remove the introducer
10) Remove the liner from the adhesive pad, and then adhere the pad to the patient’s skin. Secure
the catheter by placing the catheter attachment strap to the adhesive pad. (See Figure 7-5).
Figure 7-5 Secure the adhesive pad to mother
Rezeroing the System During Monitoring
1) With the catheter connected to the IUP cable, momentarily pressing the re-zero button on the
pressure cable (See Figure 7-6). The green light on the cable will flash for five seconds.
Figure 7-6 Rezeroing the system
2) During this period, adjust the monitor to zero by pressing the AUTO ZERO key.
WARNING :
1) Before insertion, placental position should be confirmed, amniotic membranes
