F Series Fetal & Maternal Monitor User Manual Product Specifications

- 140 -

Dimension: 88 mm × 35 mm

TOCO Transducer

Cable Length: 2.5 m

Weight: 180 g

Dimension: 88 mm × 35 mm

Remote Event Marker

Length: 2.5 m

Weight: 56 g

ECG

Cable Length: 3 m

Weight: 213 g

SpO2

Cable Length: 2.4 m

Weight: 68 g

NIBP

Cable Length: 3.3 m

Weight: 194 g

TEMP

Cable Length: 3 m

Weight: 55 g

A1.3 Performance Specifications

Ultrasound

Technique: Ultrasound Pulse Doppler with autocorrelation

Pulse Repetition Rate: 2 KHz

Pulse Duration: 92 μs

Ultrasound Frequency: (1.0±10%) MHz

Ultrasound Signal Range: 3.5uV Vpp~350 uV Vpp

p- <1 MPa

<10 mW/cm

spta

<100 mW/cm

sata

<20 mW/cm

Default Chapter2
- About this Manual2
- Product Information2
- Table of Contents4
Chapter 1 Safety Guide12
- Intended Use12
- Features13
- Instruction for Safe Operation13
- Ultrasound Safety Guide14
- Safety Precautions15
- Definitions and Symbols22
Chapter 2 Installation Guide26
- Opening and Checking Package26
- Installing Battery26
- Installing Monitor28
- Connecting Power Cable28
Chapter 3 Monitor and Accessories29
- Overview29
  - Keys and Control Knob30
  - Indicators32
- Accessories33
- Screen38
Chapter 4 Alarms44
- Alarms Classification44
- Audible Alarm44
- Visual Alarm45
- Choosing the Alarm Display Form46
- Changing the Alarm Volume46
- Choosing Alarm Silence Duration46
- Choosing Signal Loss Delay46
- Pausing or Resetting the Alarm47
- Reviewing Alarms47
- Alarm Treatment Measures48
- Testing Alarms49
- Patient Alarm Defaults49
Chapter 5 Printing51
- Function Description51
- Printing Configuration52
- Understanding the Recorder Paper Printout53
Chapter 6 Pre-Monitoring Preparation56
- Loading Recorder Paper56
- Switching on58
- Checking Recorder Paper58
- Adjusting Screen Angle59
- Setting Date and Time60
- Connecting Transducers60
- Placing Accessories in the Holder61
- Adjusting the Volume62
Chapter 7 Fetal Monitoring64
- Confirming Fetal Life64
- Monitoring FHR with Ultrasound64
- Monitoring FHR with DECG69
- Monitoring Twin Fhrs72
- Monitoring Uterine Activity Externally74
- Monitoring Uterine Activity Internally76
- Monitoring Fetal Movement80
- Start Monitoring82
- Inputting Maternal Information (Mat. Info)82
Chapter 8 Fetal Monitoring Display (F6/F9)84
- Traces84
  - Changing Time Scale85
- Trace Control Tools86
- Numerics92
  - Changing Numeric Window Position (F9)94
- Fetal Monitoring Alarm Messages94
  - Patient Alarm Messages94
  - Technical Alarm Messages94
Chapter 9 Maternal Monitoring (F6 Express/F9 Express)96
- Maternal ECG Monitoring96
- Maternal Spo Monitoring100
- Maternal HR Monitoring105
- Maternal NIBP Monitoring107
- Maternal TEMP Monitoring114
Chapter 10 Maternal Monitoring Display (F6 Express/F9 Express)116
- Display Mode116
- Maternal Monitoring Traces118
- Maternal Vital Sign List118
- Numerics119
- Maternal Monitoring Alarm Messages120
  - Patient Alarm Messages120
  - Technical Alarm Messages121
Chapter 11 FTS-3 Fetal Telemetry System124
- Brief Introduction124
- Installation Guide129
- Technical Alarm Messages134
- Basic Operation135
- Patient Application137
Chapter 12 After Monitoring140
- Completing Monitoring140
- Switching off140
Chapter 13 Maintenance and Cleaning141
- Maintenance141
- Cleaning143
  - Cleaning of Monitor and Base Station143
  - Cleaning of Accessories144
- Disinfecting146
- Sterilizing147
Chapter 14 Warranty and Service148
- Warranty148
- Contact Information148
Appendix 1 Product Specifications149
- A1.1 Environmental Specifications149
- A1.2 Physical Specifications149
- A1.3 Performance Specifications151
- A1.4 Recorder Specifications155
- A1.5 Rechargeable Lithium-Ion Battery156
- A1.6 Low Output Summary Table157
- B FTS-3 Fetal Telemetry System158
Appendix 2 Signal Input/Output Connector162
Appendix 3 Troubleshooting164
- A3.1 no Display164
- A3.2 Noise164
- A3.3 Recorder Error164
- A3.4 Trouble with Ultrasound FHR Monitoring165
- A3.5 Troubles with DECG FHR Monitoring165
- A3.6 Troubles with Contractions Monitoring (External)166
- A3.7 Troubles with Monitoring Contractions (Internal)166
- A3.8 Big ECG Signal Interference or Thick Baseline167
- A3.9 NIBP and Spo2 no Results167
- A3.10 Blown Fuses167
- B FTS-3 Fetal Telemetry System169
  - B3.1 Troubleshooting169
  - B3.2 Blown Fuses169
Appendix 4 Ultrasound Intensity and Safety172
- A4.1 Ultrasound in Medicine172
- A4.2 Ultrasound Safety and the ALARA Principle172
- A4.3 Explanation of MI/TI172
- A4.4 Prudent Use Statement174
- A4.5 References for Acoustic Output and Safety174
- A4.6 Probe Acoustic Output Parameters List175
  - A4.6.1 Test of Wired Probe175
  - A4.6.2 Test of Wireless Probe (FTS-3)179
Appendix 5 Abbreviation181
Appendix 6 Ordering Information183
Appendix 7 EMC Information185
- A7.1 Electromagnetic Emissions185
- A7.2 Electromagnetic Immunity186
- A7.3 Electromagnetic Immunity188
- A7.4 Recommended Separation Distances190
Appendix 8 Limitations of Ultrasonic Monitoring191
- A8.1 How Does Ultrasound Work191
- A8.2 Artifacts in Fetal Heart Monitoring191
- A8.3 Audio Output and Screen Reading193
