F9, F9 Express Fetal & Maternal Monitor User Manual Maternal Monitoring Display
- 142 -
Figure 10-7 Maternal Numeric Window
SpO
2
99: Current SpO
2
measurement numeric.
100: SpO
2
alarm upper limit
90: SpO
2
alarm lower limit
: SpO
2
indicator.
SI: Signal intensity.
NIBP
18:45: Time when the NIBP measurement starts.
mmHg: NIBP unit.
From left to right, top to bottom in turn: current systolic pressure (117),
mean artery pressure (91),diastolic pressure (78) and PR (64).
(manual): The current NIBP measurement mode is manual.
HR
(ECG): The current HR comes from ECG.
63: Current maternal heart rate measurement numeric.
FHR1
FHR2
TOCO
MFM
NIBP
HR
SpO
2
TEMP
