Eden C1P2FXBT - Other Communication Methods; DONGLE Installation

Technical manual C1P2FXBT – V1.7 p 22/28
2) Other communication methods
Communication
method
Description
Reference
Ethernet net-
work (TCP/IP):
LAN, WAN,
VPN, ADSL,
WLAN (WIFI)
Wired connection of an RS485
bus on several control units to the
Ethernet network
C485FX + MOD-TCPIP
Wired connection of a single
control unit to the Ethernet net-
work
MOD-TCPIP
For more information on these different modules, please refer to the technical documentation
supplied with each module.
3) DONGLE Installation
DONGLE
Description
DONGLEFXCD16
License to connect up to 16 readers
DONGLEFXCD64
License to connect up to 64 readers
DONGLEFXCD512
License to connect up to 128 readers
Dongle
FX
