Technical manual C1P2FXBT – V1.7 p 7/28
Typical arrangement for connection
1) Active aerial
Data sheet:
0.6 mm (1/30 in) (SYT recommended)
Characteristic: Sensitive connection
Screen: Mandatory
Simply connect the three wires on the reader to the control unit terminal block as shown.
Note: Do not position the control unit-receiver wires close to other live or high voltage cables
and specifically not close to 230 V cables or higher.
Radio receiver
(JCM, TECHNO EM,…)
