Quick Start Guide
– 7 –
Note:
For International use, you may need to change the AC line cord. You must
use a line cord set that has been approved for the socket type in your country.
Extended Power Supply—EPS460W
Install the ECS2100-28PP in a standard 19-inch rack and power on.
Install the PS3000 chassis in a standard 19-inch rack.
Install one or more EPS460W PSUs in the chassis. The chassis can support up to three EPS460W
PSUs.
Use the PSU cable (provided) to connect each EPS460W PSU to an ECS2100-28PP switch.
Connect the AC power cord to power on the EPS460W PSU, and check the LEDs on the PSUs to
ensure proper operation. The Link LEDs for connected switches should light up.
