1 INTRODUCTION
OVERVIEW
The ECS4310-26T is a Gigabit Smart Switch with 24 1000BASE-T ports, and two
1000BASE-T ports Small Form Factor Pluggable (SFP) transceiver slots. The
switch also includes an SNMP-based management agent, which provides both
in-band and out-of-band access for managing the switch.
The ECS4310-26T provides a broad range of powerful features for Layer 2
switching, delivering reliability and consistent performance for your network
traffic. It brings order to poorly performing networks by segregating them into
separate broadcast domains with IEEE 802.1Q compliant VLANs, and empowers
multimedia applications with multicast switching and CoS services.
Figure 1: Front Panel
Figure 2: Rear Panel
