C
HAPTER
1
| Introduction
Overview
– 24 –
Figure 1: Front Panel
Figure 2: Rear Panel
Port Status Indicators
1000BASE-T/SFP
Combination Ports
System Indicators
RJ-45 Console Port
1000BASE-X SFP Ports
Power Socket
Grounding Point
