Edge-Core ECS4620-28F-2AC Cli Reference Guide

Chapter 50 | IP Routing Commands
Border Gateway Protocol (BGPv4)
– 1125 –
Command Mode
Router Configuration
Default Setting
Disabled
Example
Console(config-router)#neighbor 10.1.1.64 override-capability
Console(config-router)#
neighbor passive This command passively forms a connection with the specified neighbor, not
sending a TCP connection request, but waiting a connection request from the
specified neighbor. Use the no form to disable this feature.
Syntax
[no] neighbor {ip-address | group-name} passive
ip-address – IP address of a neighbor.
group-name – A BGP peer group containing a list of neighboring routers
configured with the neighbor peer-group command.
Command Mode
Router Configuration
Default Setting
Disabled
Command Usage
This command configures the local router so that it remains in Active state, waiting
for an inbound connection request from a neighbor, and not initiating any
outbound connections with the neighbor via an Open message.
Example
Console(config-router)#neighbor 10.1.1.64 passive
Console(config-router)#

Edge-Core ECS4620-28F-2AC Specifications

General

Model	ECS4620-28F-2AC
Ports	28
SFP Ports	24
Power over Ethernet (PoE)	No
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	L2/L3
MAC Address Table Size	16K
VLANs	4K
Weight	3.5 kg
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Type	Switch
10G SFP+ Ports	4
Power Supply	AC: 100~240VAC, 50/60 Hz
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1P, IEEE 802.1D, IEEE 802.1S, IEEE 802.1W
